ECS-100-S-1无源晶振,ECS插件晶振,HC-49U石英晶振

原厂型号 Original model ：	ECS-100-S-1
品牌 brand ：	ECS晶振
型号名称 Model name：	HC-49U
Type 系列：	MHz Crystal
频率 frequency ：	10MHz
Frequency Stability频率稳定度	±50ppm
frequency tolerance频率容差	±30ppm
Load capacitance 负载电容	Series
Size / Dimension 尺寸	11.35mm x 4.65mm

订购热线：0755-27838351

ECS-100-S-1无源晶振,ECS插件晶振,HC-49U石英晶振

原厂型号 Original model ：	ECS-100-S-1	品牌 brand ：	ECS伊西斯无源晶振
品牌 brand ：	ECS无源晶振	ESR（等效串联电阻）ESR (Equivalent Series Resistance)	30 Ohm
型号名称 Model name：	HC-49U	温度 Operating Temperature	-10°C ~ 70°C
Type 系列：	MHz Crystal	脚位 Termination：	2 pad
频率 frequency ：	10MHz	封装类型 Package Type：	HC49/U石英晶振
Frequency Stability频率稳定度	±50ppm	高度 Package Height：	13.46mm
frequency tolerance频率容差	±30ppm	最小包装数 MPQ ：	-
Load capacitance 负载电容	Series	包装 Packaging：	Tape and Reel
Size / Dimension 尺寸	11.35mm x 4.65mm	安装方式 Mounting Style：	Surface Mount

ECS-100-S-1无源晶振,ECS插件晶振,HC-49U石英晶振

ECS-100-S-1	HC-49U	MHz Crystal	10MHz	±50ppm	±30ppm	Series	30 Ohm
ECS-102.4-S-1	HC-49U	MHz Crystal	10.24MHz	±50ppm	±30ppm	Series	30 Ohm
ECS-107.3-S-1	HC-49U	MHz Crystal	10.738635MHz	±50ppm	±30ppm	Series	30 Ohm
ECS-110.4-S-1	HC-49U	MHz Crystal	11.046MHz	±50ppm	±30ppm	Series	30 Ohm
ECS-110.5-20-1	HC-49U	MHz Crystal	11.0592MHz	±50ppm	±30ppm	20pF	30 Ohm
ECS-110.5-32-1	HC-49U	MHz Crystal	11.0592MHz	±50ppm	±30ppm	32pF	30 Ohm
ECS-110.5-S-1	HC-49U	MHz Crystal	11.0592MHz	±50ppm	±30ppm	Series	30 Ohm
ECS-110-S-1	HC-49U	MHz Crystal	11MHz	±50ppm	±30ppm	Series	30 Ohm
ECS-112.2-S-1	HC-49U	MHz Crystal	11.228MHz	±50ppm	±30ppm	Series	30 Ohm
ECS-115.2-S-1	HC-49U	MHz Crystal	11.52MHz	±50ppm	±30ppm	Series	30 Ohm
ECS-119.8-S-1	HC-49U	MHz Crystal	11.98135MHz	±50ppm	±30ppm	Series	30 Ohm
ECS-120.003-18-1	HC-49U	MHz Crystal	12.000393MHz	±50ppm	±30ppm	18pF	30 Ohm
ECS-120-32-1	HC-49U	MHz Crystal	12MHz	±50ppm	±30ppm	32pF	30 Ohm
ECS-120-S-1	HC-49U	MHz Crystal	12MHz	±50ppm	±30ppm	Series	30 Ohm
ECS-121-S-1	HC-49U	MHz Crystal	12.096MHz	±50ppm	±30ppm	Series	30 Ohm
ECS-122.8-20-1	HC-49U	MHz Crystal	12.288MHz	±50ppm	±30ppm	20pF	30 Ohm
ECS-122.8-S-1	HC-49U	MHz Crystal	12.288MHz	±50ppm	±30ppm	Series	30 Ohm
ECS-135-S-1	HC-49U	MHz Crystal	13.5168MHz	±50ppm	±30ppm	Series	25 Ohm
ECS-143-S-1	HC-49U	MHz Crystal	14.31818MHz	±50ppm	±30ppm	Series	25 Ohm
ECS-146-S-1	HC-49U	MHz Crystal	14.69MHz	±50ppm	±30ppm	Series	25 Ohm
ECS-147.4-20-1	HC-49U	MHz Crystal	14.7456MHz	±50ppm	±30ppm	20pF	25 Ohm
ECS-147.4-S-1	HC-49U	MHz Crystal	14.7456MHz	±50ppm	±30ppm	Series	25 Ohm
ECS-150-S-1	HC-49U	MHz Crystal	15MHz	±50ppm	±30ppm	Series	25 Ohm
ECS-160.003-18-1	HC-49U	MHz Crystal	16.000312MHz	±50ppm	±30ppm	18pF	20 Ohm
ECS-160-20-1	HC-49U	MHz Crystal	16MHz	±50ppm	±30ppm	20pF	20 Ohm
ECS-160-S-1	HC-49U	MHz Crystal	16MHz	±50ppm	±30ppm	Series	20 Ohm
ECS-180-20-1	HC-49U	MHz Crystal	18MHz	±50ppm	±30ppm	20pF	20 Ohm
ECS-180-S-1	HC-49U	MHz Crystal	18MHz	±50ppm	±30ppm	Series	20 Ohm
ECS-18-13-1	HC-49U	MHz Crystal	1.8432MHz	±50ppm	±30ppm	13pF	750 Ohm
ECS-18-32-1	HC-49U	MHz Crystal	1.8432MHz	±50ppm	±30ppm	32pF	750 Ohm
ECS-184-18-1	HC-49U	MHz Crystal	18.432MHz	±50ppm	±30ppm	18pF	20 Ohm
ECS-184-20-1	HC-49U	MHz Crystal	18.432MHz	±50ppm	±30ppm	20pF	20 Ohm
ECS-184-S-1	HC-49U	MHz Crystal	18.432MHz	±50ppm	±30ppm	Series	20 Ohm
ECS-18-S-1	HC-49U	MHz Crystal	1.8432MHz	±50ppm	±30ppm	Series	750 Ohm
ECS-196.6-20-1	HC-49U	MHz Crystal	19.6608MHz	±50ppm	±30ppm	20pF	20 Ohm
ECS-196.6-S-1	HC-49U	MHz Crystal	19.6608MHz	±50ppm	±30ppm	Series	20 Ohm
ECS-20.48-12-1	HC-49U	MHz Crystal	2.048MHz	±50ppm	±30ppm	12pF	500 Ohm
ECS-200-20-1	HC-49U	MHz Crystal	20MHz	±50ppm	±30ppm	20pF	20 Ohm
ECS-200-S-1	HC-49U	MHz Crystal	20MHz	±50ppm	±30ppm	Series	20 Ohm
ECS-20-20-1	HC-49U	MHz Crystal	2MHz	±50ppm	±30ppm	20pF	500 Ohm
ECS-20-S-1	HC-49U	MHz Crystal	2MHz	±50ppm	±30ppm	Series	500 Ohm
ECS-221-S-1	HC-49U	MHz Crystal	22.1184MHz	±50ppm	±30ppm	Series	20 Ohm
ECS-240.001-18-1	HC-49U	MHz Crystal	24.00014MHz	±50ppm	±30ppm	18pF	20 Ohm
ECS-240-20-1	HC-49U	MHz Crystal	24MHz	±50ppm	±30ppm	20pF	20 Ohm
ECS-240-S-1	HC-49U	MHz Crystal	24MHz	±50ppm	±30ppm	Series	20 Ohm
ECS-24-32-1	HC-49U	MHz Crystal	2.4576MHz	±50ppm	±30ppm	32pF	300 Ohm
ECS-25-S-1	HC-49U	MHz Crystal	2.5MHz	±50ppm	±30ppm	Series	300 Ohm
ECS-30-S-1	HC-49U	MHz Crystal	3MHz	±50ppm	±30ppm	Series	200 Ohm
ECS-32-17-1	HC-49U	MHz Crystal	3.2768MHz	±50ppm	±30ppm	17pF	120 Ohm
ECS-35-17-1	HC-49U	MHz Crystal	3.579545MHz	±50ppm	±30ppm	17pF	120 Ohm
ECS-352.5-18-1	HC-49U	MHz Crystal	35.2512MHz	±50ppm	±30ppm	18pF	40 Ohm
ECS-35-S-1	HC-49U	MHz Crystal	3.579545MHz	±50ppm	±30ppm	Series	120 Ohm
ECS-36-18-1	HC-49U	MHz Crystal	3.6864MHz	±50ppm	±30ppm	18pF	120 Ohm
ECS-36-S-1	HC-49U	MHz Crystal	3.6864MHz	±50ppm	±30ppm	Series	120 Ohm
ECS-380.005-18-1	HC-49U	MHz Crystal	38.00053MHz	±50ppm	±30ppm	18pF	40 Ohm
ECS-39-17-1	HC-49U	MHz Crystal	3.93216MHz	±50ppm	±30ppm	17pF	100 Ohm
ECS-40.3-20-1	HC-49U	MHz Crystal	4.032MHz	±50ppm	±30ppm	20pF	100 Ohm
ECS-40.3-S-1	HC-49U	MHz Crystal	4.032MHz	±50ppm	±30ppm	Series	100 Ohm
ECS-40-20-1	HC-49U	MHz Crystal	4MHz	±50ppm	±30ppm	20pF	100 Ohm
ECS-403.2-18-1	HC-49U	MHz Crystal	40.32MHz	±50ppm	±30ppm	18pF	40 Ohm
