ECS-100-20-28A-TR,ECS伊西斯无源晶振,CSM-4A石英晶振

原厂型号 Original model ：	ECS-100-20-28A-TR
品牌 brand ：	ECS伊西斯晶振
型号名称 Model name：	CSM-4A
Type 系列：	MHz Crystal
频率 frequency ：	10MHz
Frequency Stability频率稳定度	±50ppm
frequency tolerance频率容差	±30ppm
Load capacitance 负载电容	20pF
Size / Dimension 尺寸	12.50mm x 4.85mm

订购热线：0755-27838351

ECS-100-20-28A-TR,ECS伊西斯无源晶振,CSM-4A石英晶振

原厂型号 Original model ：	ECS-100-20-28A-TR	品牌 brand ：	ECS伊西斯晶振
品牌 brand ：	ECS伊西斯晶振	ESR（等效串联电阻）ESR (Equivalent Series Resistance)	60 Ohm
型号名称 Model name：	CSM-4A	温度 Operating Temperature	-10°C ~ 70°C
Type 系列：	MHz Crystal	脚位 Termination：	2 pad
频率 frequency ：	10MHz	封装类型 Package Type：	HC49/US
Frequency Stability频率稳定度	±50ppm	高度 Package Height：	5.00mm
frequency tolerance频率容差	±30ppm	最小包装数 MPQ ：	-
Load capacitance 负载电容	20pF	包装 Packaging：	Tape and Reel
Size / Dimension 尺寸	12.50mm x 4.85mm	安装方式 Mounting Style：	Surface Mount

ECS-100-20-28A-TR,ECS伊西斯无源晶振,CSM-4A石英晶振

ECS-120-20-3X-EN-TR	CSM-3X	MHz Crystal	12MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-120-20-3X-TR	CSM-3X	MHz Crystal	12MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-122.8-20-3X-EN-TR	CSM-3X无源晶振	MHz Crystal	12.288MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-122.8-20-3X-TR	CSM-3X	MHz Crystal	12.288MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-130-20-3X-EN-TR	CSM-3X	MHz Crystal	13MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-130-20-3X-TR	CSM-3X	MHz Crystal	13MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-135.6-20-3X-EN-TR	CSM-3X	MHz Crystal	13.56MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-135.6-20-3X-TR	CSM-3X	MHz Crystal	13.56MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-143-20-3X-EN-TR	CSM-3X	MHz Crystal	14.31818MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-143-20-3X-TR	CSM-3X	MHz Crystal	14.31818MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-147.4-20-3X-EN-TR	CSM-3X	MHz Crystal	14.7456MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-147.4-20-3X-TR	CSM-3X	MHz Crystal	14.7456MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-160-20-3X-EN-TR	CSM-3X	MHz Crystal	16MHz	±50ppm	±30ppm	20pF	50 Ohm
ECS-160-20-3X-TR	CSM-3X	MHz Crystal	16MHz	±50ppm	±30ppm	20pF	50 Ohm
ECS-184-20-3X-EN-TR	CSM-3X	MHz Crystal	18.432MHz	±50ppm	±30ppm	20pF	50 Ohm
ECS-184-20-3X-TR	CSM-3X	MHz Crystal	18.432MHz	±50ppm	±30ppm	20pF	50 Ohm
ECS-196.6-20-3X-EN-TR	CSM-3X	MHz Crystal	19.6608MHz	±50ppm	±30ppm	20pF	50 Ohm
ECS-196.6-20-3X-TR	CSM-3X	MHz Crystal	19.6608MHz	±50ppm	±30ppm	20pF	50 Ohm
ECS-200-20-3X-EN-TR	CSM-3X	MHz Crystal	20MHz	±50ppm	±30ppm	20pF	50 Ohm
ECS-200-20-3X-TR	CSM-3X	MHz Crystal	20MHz	±50ppm	±30ppm	20pF	50 Ohm
ECS-200-CDX-0914	CSM-3X	MHz Crystal	20MHz	±30ppm	±10ppm	10pF	50 Ohm
ECS-245.7-20-3X-EN-TR	CSM-3X	MHz Crystal	24.576MHz	±50ppm	±30ppm	20pF	50 Ohm
ECS-245.7-20-3X-TR	CSM-3X	MHz Crystal	24.576MHz	±50ppm	±30ppm	20pF	50 Ohm
ECS-250-20-3X-EN-TR	CSM-3X	MHz Crystal	25MHz	±50ppm	±30ppm	20pF	50 Ohm
ECS-250-20-3X-TR	CSM-3X	MHz Crystal	25MHz	±50ppm	±30ppm	20pF	50 Ohm
ECS-270-20-3X-EN-TR	CSM-3X	MHz Crystal	27MHz	±50ppm	±30ppm	20pF	50 Ohm
ECS-270-20-3X-TR	CSM-3X	MHz Crystal	27MHz	±50ppm	±30ppm	20pF	50 Ohm
ECS-286.3-20-3X-EN-TR	CSM-3X	MHz Crystal	28.63636MHz	±50ppm	±30ppm	20pF	50 Ohm
ECS-286.3-20-3X-TR	CSM-3X	MHz Crystal	28.63636MHz	±50ppm	±30ppm	20pF	50 Ohm
ECS-300-20-3X-EN-TR	CSM-3X	MHz Crystal	30MHz	±50ppm	±30ppm	20pF	40 Ohm
ECS-300-20-3X-TR	CSM-3X	MHz Crystal	30MHz	±50ppm	±30ppm	20pF	40 Ohm
ECS-330-20-3X-EN-TR	CSM-3X	MHz Crystal	33MHz	±50ppm	±30ppm	20pF	40 Ohm
ECS-330-20-3X-TR	CSM-3X	MHz Crystal	33MHz	±50ppm	±30ppm	20pF	40 Ohm
ECS-400-20-3X-EN-TR	CSM-3X	MHz Crystal	40MHz	±50ppm	±30ppm	20pF	40 Ohm
ECS-400-20-3X-TR	CSM-3X	MHz Crystal	40MHz	±50ppm	±30ppm	20pF	40 Ohm
ECS-100-20-28A-TR	CSM-4A	MHz Crystal	10MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-100-S-28A-TR	CSM-4A	MHz Crystal	10MHz	±50ppm	±30ppm	Series	60 Ohm
ECS-110.5-20-28A-TR	CSM-4A	MHz Crystal	11.0592MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-110.5-S-28A-TR	CSM-4A	MHz Crystal	11.0592MHz	±50ppm	±30ppm	Series	60 Ohm
ECS-120-18-28A-TR	CSM-4A	MHz Crystal	12MHz	±50ppm	±30ppm	18pF	60 Ohm
ECS-120-32-28A-TR	CSM-4A	MHz Crystal	12MHz	±50ppm	±30ppm	32pF	60 Ohm
ECS-120-S-28A-TR	CSM-4A	MHz Crystal	12MHz	±50ppm	±30ppm	Series	60 Ohm
ECS-122.8-20-28A-TR	CSM-4A	MHz Crystal	12.288MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-143-20-28A-TR	CSM-4A	MHz Crystal	14.31818MHz	±50ppm	±30ppm	20pF	40 Ohm
ECS-143-S-28A-TR	CSM-4A	MHz Crystal	14.31818MHz	±50ppm	±30ppm	Series	40 Ohm
ECS-147.4-20-28A-TR	CSM-4A	MHz Crystal	14.7456MHz	±50ppm	±30ppm	20pF	40 Ohm
ECS-147.4-S-28A-TR	CSM-4A	MHz Crystal	14.7456MHz	±50ppm	±30ppm	Series	40 Ohm
ECS-160-20-28A-TR	CSM-4A	MHz Crystal	16MHz	±50ppm	±30ppm	20pF	40 Ohm
ECS-160-S-28A-TR	CSM-4A	MHz Crystal	16MHz	±50ppm	±30ppm	Series	40 Ohm
ECS-184-20-28A-TR	CSM-4A	MHz Crystal	18.432MHz	±50ppm	±30ppm	20pF	40 Ohm
ECS-184-S-28A-TR	CSM-4A	MHz Crystal	18.432MHz	±50ppm	±30ppm	Series	40 Ohm
ECS-200-20-28A-TR	CSM-4A	MHz Crystal	20MHz	±50ppm	±30ppm	20pF	30 Ohm
ECS-200-S-28A-TR	CSM-4A	MHz Crystal	20MHz	±50ppm	±30ppm	Series	30 Ohm
ECS-240-12-28A-TR	CSM-4A	MHz Crystal	24MHz	±50ppm	±30ppm	12pF	30 Ohm
ECS-240-20-28A-TR	CSM-4A	MHz Crystal	24MHz	±50ppm	±30ppm	20pF	30 Ohm
ECS-240-S-28A-TR	CSM-4A	MHz Crystal	24MHz	±50ppm	±30ppm	Series	30 Ohm
ECS-245.7-20-28A-TR	CSM-4A	MHz Crystal	24.576MHz	±50ppm	±30ppm	20pF	30 Ohm
ECS-250-20-28A-F-TR	CSM-4A	MHz Crystal	25MHz	±50ppm	±30ppm	20pF	30 Ohm
ECS-35-17-28A-TR	CSM-4A	MHz Crystal	3.579545MHz	±50ppm	±30ppm	17pF	200 Ohm
ECS-36-20-28A-TR	CSM-4A	MHz Crystal	3.6864MHz	±50ppm	±30ppm	20pF	200 Ohm
