ECS-120-20-3X-EN-TR,ECS石英贴片晶振,CSM-3X无源晶振

原厂型号 Original model ：	ECS-120-20-3X-EN-TR
品牌 brand ：	ECS伊西斯晶振
型号名称 Model name：	CSM-3X
Type 系列：	MHz Crystal
频率 frequency ：	12MHz
Frequency Stability频率稳定度	±50ppm
frequency tolerance频率容差	±30ppm
Load capacitance 负载电容	20pF
Size / Dimension 尺寸	7.00mm x 4.10mm

订购热线：0755-27838351

ECS-120-20-3X-EN-TR,ECS石英贴片晶振,CSM-3X无源晶振

原厂型号 Original model ：	ECS-120-20-3X-EN-TR	品牌 brand ：	ECS伊西斯晶振
品牌 brand ：	ECS伊西斯晶振	ESR（等效串联电阻）ESR (Equivalent Series Resistance)	60 Ohm
型号名称 Model name：	CSM-3X	温度 Operating Temperature	-40°C ~ 85°C
Type 系列：	MHz Crystal	脚位 Termination：	2 pad
频率 frequency ：	12MHz	封装类型 Package Type：	HC49/US晶振
Frequency Stability频率稳定度	±50ppm	高度 Package Height：	2.30mm
frequency tolerance频率容差	±30ppm	最小包装数 MPQ ：	-
Load capacitance 负载电容	20pF	包装 Packaging：	Tape and Reel
Size / Dimension 尺寸	7.00mm x 4.10mm	安装方式 Mounting Style：	Surface Mount

ECS-120-20-3X-EN-TR,ECS石英贴片晶振,CSM-3X无源晶振

ECS-100-18-18-TR	CSM-12	MHz Crystal	10MHz	±100ppm	±30ppm	18pF	80 Ohm
ECS-100-S-18-TR	CSM-12	MHz Crystal	10MHz	±100ppm	±30ppm	Series	80 Ohm
ECS-110.5-18-18-TR	CSM-12	MHz Crystal	11.0592MHz	±100ppm	±30ppm	18pF	80 Ohm
ECS-110.5-20-18-TR	CSM-12	MHz Crystal	11.0592MHz	±100ppm	±30ppm	20pF	80 Ohm
ECS-110.5-S-18-TR	CSM-12	MHz Crystal	11.0592MHz	±100ppm	±30ppm	Series	80 Ohm
ECS-112.896-18-18-TR	CSM-12	MHz Crystal	11.2896MHz	±100ppm	±30ppm	18pF	80 Ohm
ECS-120-18-18-TR	CSM-12	MHz Crystal	12MHz	±100ppm	±30ppm	18pF	80 Ohm
ECS-120-S-18-TR	CSM-12	MHz Crystal	12MHz	±100ppm	±30ppm	Series	80 Ohm
ECS-122.8-18-18-TR	CSM-12	MHz Crystal	12.288MHz	±100ppm	±30ppm	18pF	80 Ohm
ECS-143-20-18-TR	CSM-12	MHz Crystal	14.31818MHz	±100ppm	±30ppm	20pF	50 Ohm
ECS-143-S-18-TR	CSM-12	MHz Crystal	14.31818MHz	±100ppm	±30ppm	Series	50 Ohm
ECS-147.4-18-18-TR	CSM-12	MHz Crystal	14.7456MHz	±100ppm	±30ppm	18pF	50 Ohm
ECS-153.6-18-18-TR	CSM-12	MHz Crystal	15.36MHz	±100ppm	±30ppm	18pF	50 Ohm
ECS-160-18-18-TR	CSM-12	MHz Crystal	16MHz	±100ppm	±30ppm	18pF	50 Ohm
ECS-160-S-18-TR	CSM-12	MHz Crystal	16MHz	±100ppm	±30ppm	Series	50 Ohm
ECS-166.66-18-18-TR	CSM-12	MHz Crystal	16.666MHz	±100ppm	±30ppm	18pF	50 Ohm
ECS-184-18-18-TR	CSM-12	MHz Crystal	18.432MHz	±100ppm	±30ppm	18pF	50 Ohm
ECS-184-S-18-TR	CSM-12	MHz Crystal	18.432MHz	±100ppm	±30ppm	Series	50 Ohm
ECS-196.6-S-18-TR	CSM-12	MHz Crystal	19.6608MHz	±100ppm	±30ppm	Series	50 Ohm
ECS-200-18-18-TR	CSM-12	MHz Crystal	20MHz	±100ppm	±30ppm	18pF	50 Ohm
ECS-200-20-18-TR	CSM-12	MHz Crystal	20MHz	±100ppm	±30ppm	20pF	50 Ohm
ECS-200-S-18-TR	CSM-12	MHz Crystal	20MHz	±100ppm	±30ppm	Series	50 Ohm
ECS-204.8-18-18-TR	CSM-12	MHz Crystal	20.48MHz	±100ppm	±30ppm	18pF	50 Ohm
ECS-221-18-18-TR	CSM-12	MHz Crystal	22.1184MHz	±100ppm	±30ppm	18pF	50 Ohm
ECS-240-16-18-TR	CSM-12	MHz Crystal	24MHz	±100ppm	±30ppm	16pF	50 Ohm
ECS-240-18-18-TR	CSM-12	MHz Crystal	24MHz	±100ppm	±30ppm	18pF	50 Ohm
ECS-240-20-18-TR	CSM-12	MHz Crystal	24MHz	±100ppm	±30ppm	20pF	50 Ohm
ECS-245.7-18-18-TR	CSM-12	MHz Crystal	24.576MHz	±100ppm	±30ppm	18pF	50 Ohm
ECS-250-18-18-TR	CSM-12	MHz Crystal	25MHz	±100ppm	±30ppm	18pF	40 Ohm
ECS-35-17-18-TR	CSM-12	MHz Crystal	3.579545MHz	±100ppm	±30ppm	17pF	200 Ohm
ECS-35-18-18-TR	CSM-12	MHz Crystal	3.579545MHz	±100ppm	±30ppm	18pF	200 Ohm
ECS-36-18-18-TR	CSM-12	MHz Crystal	3.6864MHz	±100ppm	±30ppm	18pF	200 Ohm
ECS-36-20-18-TR	CSM-12	MHz Crystal	3.6864MHz	±100ppm	±30ppm	20pF	200 Ohm
ECS-36-S-18-TR	CSM-12	MHz Crystal	3.6864MHz	±100ppm	±30ppm	Series	200 Ohm
ECS-40-18-18-TR	CSM-12	MHz Crystal	4MHz	±100ppm	±30ppm	18pF	150 Ohm
ECS-40-20-18-TR	CSM-12	MHz Crystal	4MHz	±100ppm	±30ppm	20pF	150 Ohm
ECS-40-S-18-TR	CSM-12	MHz Crystal	4MHz	±100ppm	±30ppm	Series	150 Ohm
ECS-41-18-18-TR	CSM-12	MHz Crystal	4.096MHz	±100ppm	±30ppm	18pF	150 Ohm
ECS-49-18-18-TR	CSM-12	MHz Crystal	4.9152MHz	±100ppm	±30ppm	18pF	150 Ohm
ECS-49-20-18-TR	CSM-12	MHz Crystal	4.9152MHz	±100ppm	±30ppm	20pF	150 Ohm
ECS-49-S-18-TR	CSM-12	MHz Crystal	4.9152MHz	±100ppm	±30ppm	Series	150 Ohm
ECS-50-18-18-TR	CSM-12	MHz Crystal	5MHz	±100ppm	±30ppm	18pF	150 Ohm
ECS-60-18-18-TR	CSM-12	MHz Crystal	6MHz	±100ppm	±30ppm	18pF	100 Ohm
ECS-61-18-18-TR	CSM-12	MHz Crystal	6.144MHz	±100ppm	±30ppm	18pF	100 Ohm
ECS-61-32-18-TR	CSM-12	MHz Crystal	6.144MHz	±100ppm	±30ppm	32pF	100 Ohm
ECS-73-18-18-TR	CSM-12	MHz Crystal	7.3728MHz	±100ppm	±30ppm	18pF	100 Ohm
ECS-73-20-18	CSM-12	MHz Crystal	7.3728MHz	±100ppm	±30ppm	20pF	100 Ohm
ECS-73-S-18-TR	CSM-12	MHz Crystal	7.3728MHz	±100ppm	±30ppm	Series	100 Ohm
ECS-80-18-18-TR	CSM-12	MHz Crystal	8MHz	±100ppm	±30ppm	18pF	100 Ohm
ECS-80-20-18-TR	CSM-12	MHz Crystal	8MHz	±100ppm	±30ppm	20pF	100 Ohm
ECS-80-S-18-TR	CSM-12	MHz Crystal	8MHz	±100ppm	±30ppm	Series	100 Ohm
ECS-98.3-20-18-TR	CSM-12	MHz Crystal	9.8304MHz	±100ppm	±30ppm	20pF	100 Ohm
ECS-98.3-S-18-TR	CSM-12	MHz Crystal	9.8304MHz	±100ppm	±30ppm	Series	100 Ohm
ECS-120-20-3X-EN-TR	CSM-3X	MHz Crystal	12MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-120-20-3X-TR	CSM-3X	MHz Crystal	12MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-122.8-20-3X-EN-TR	CSM-3X	MHz Crystal	12.288MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-122.8-20-3X-TR	CSM-3X	MHz Crystal	12.288MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-130-20-3X-EN-TR	CSM-3X	MHz Crystal	13MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-130-20-3X-TR	CSM-3X	MHz Crystal	13MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-135.6-20-3X-EN-TR	CSM-3X	MHz Crystal	13.56MHz	±50ppm	±30ppm	20pF	60 Ohm
