ECS-100-18-5PX-TR,ECS伊西斯无源晶振,CSM-7X贴片晶振

原厂型号 Original model ：	ECS-100-18-5PX-TR
品牌 brand ：	ECS伊西斯晶振
型号名称 Model name：	CSM-7X
Type 系列：	MHz Crystal
频率 frequency ：	10MHz
Frequency Stability频率稳定度	±50ppm
frequency tolerance频率容差	±30ppm
Load capacitance 负载电容	18pF
Size / Dimension 尺寸	11.40mm x 4.80mm

订购热线：0755-27838351

ECS-100-18-5PX-TR,ECS伊西斯无源晶振,CSM-7X贴片晶振

原厂型号 Original model ：	ECS-100-18-5PX-TR	品牌 brand ：	ECS伊西斯晶振
品牌 brand ：	ECS伊西斯石英贴片晶振	ESR（等效串联电阻）ESR (Equivalent Series Resistance)	50 Ohm
型号名称 Model name：	CSM-7X	温度 Operating Temperature	-10°C ~ 70°C
Type 系列：	MHz Crystal	脚位 Termination：	2 pad
频率 frequency ：	10MHz	封装类型 Package Type：	HC49/US
Frequency Stability频率稳定度	±50ppm	高度 Package Height：	4.30mm
frequency tolerance频率容差	±30ppm	最小包装数 MPQ ：	-
Load capacitance 负载电容	18pF	包装 Packaging：	Tape and Reel
Size / Dimension 尺寸	11.40mm x 4.80mm	安装方式 Mounting Style：	Surface Mount

ECS-100-18-5PX-TR,ECS伊西斯无源晶振,CSM-7X贴片晶振

ECS-80-20-5PVX	CSM-7SSX无源谐振器	MHz Crystal	8MHz	±50ppm	±30ppm	20pF	80 Ohm
ECS-98.3-20-5PVX	CSM-7SSX	MHz Crystal	9.8304MHz	±50ppm	±30ppm	20pF	60 Ohm
ECS-100-18-5PX-TR	CSM-7X	MHz Crystal	10MHz	±50ppm	±30ppm	18pF	50 Ohm
ECS-100-S-5PX-TR	CSM-7X	MHz Crystal	10MHz	±50ppm	±30ppm	Series	50 Ohm
ECS-102.4-18-5PXEN	CSM-7X	MHz Crystal	10.24MHz	±50ppm	±30ppm	18pF	50 Ohm
ECS-102.45-16-5PX-TR	CSM-7X	MHz Crystal	10.245MHz	±50ppm	±30ppm	16pF	50 Ohm
ECS-110.5-18-5PXEN-TR	CSM-7X	MHz Crystal	11.0592MHz	±50ppm	±30ppm	18pF	50 Ohm
ECS-110.5-20-5PX-TR	CSM-7X	MHz Crystal	11.0592MHz	±50ppm	±30ppm	20pF	50 Ohm
ECS-110.5-32-5PX-TR	CSM-7X	MHz Crystal	11.0592MHz	±50ppm	±30ppm	32pF	50 Ohm
ECS-110.5-S-5PX-TR	CSM-7X	MHz Crystal	11.0592MHz	±50ppm	±30ppm	Series	50 Ohm
ECS-110-18-5PXEN-TR	CSM-7X	MHz Crystal	11MHz	±50ppm	±30ppm	18pF	50 Ohm
ECS-115.2-18-5PXEN	CSM-7X	MHz Crystal	11.52MHz	±50ppm	±30ppm	18pF	50 Ohm
ECS-120.003-18-5PXEN	CSM-7X	MHz Crystal	12.000393MHz	±50ppm	±30ppm	18pF	50 Ohm
ECS-120-18-5PX-TR	CSM-7X	MHz Crystal	12MHz	±50ppm	±30ppm	18pF	50 Ohm
ECS-120-32-5PX-TR	CSM-7X	MHz Crystal	12MHz	±50ppm	±30ppm	32pF	50 Ohm
ECS-120-S-5PX-TR	CSM-7X	MHz Crystal	12MHz	±50ppm	±30ppm	Series	50 Ohm
ECS-122.8-18-5PXEN-TR	CSM-7X	MHz Crystal	12.288MHz	±50ppm	±30ppm	18pF	50 Ohm
ECS-122.8-20-5PX-TR	CSM-7X	MHz Crystal	12.288MHz	±50ppm	±30ppm	20pF	50 Ohm
ECS-122.8-S-5PX-TR	CSM-7X	MHz Crystal	12.288MHz	±50ppm	±30ppm	Series	50 Ohm
ECS-135.6-12-5PX-TR	CSM-7X	MHz Crystal	13.56MHz	±50ppm	±30ppm	12pF	40 Ohm
ECS-135-18-5PXEN-TR	CSM-7X	MHz Crystal	13.5168MHz	±50ppm	±30ppm	18pF	40 Ohm
ECS-143-18-5PXEN-TR	CSM-7X	MHz Crystal	14.31818MHz	±50ppm	±30ppm	18pF	40 Ohm
ECS-143-20-5PX-TR	CSM-7X	MHz Crystal	14.31818MHz	±50ppm	±30ppm	20pF	40 Ohm
ECS-143-S-5PX-TR	CSM-7X	MHz Crystal	14.31818MHz	±50ppm	±30ppm	Series	40 Ohm
ECS-147.4-18-5PXEN-TR	CSM-7X	MHz Crystal	14.7456MHz	±50ppm	±30ppm	18pF	40 Ohm
ECS-147.4-20-5PX-TR	CSM-7X	MHz Crystal	14.7456MHz	±50ppm	±30ppm	20pF	40 Ohm
ECS-147.4-S-5PX-TR	CSM-7X	MHz Crystal	14.7456MHz	±50ppm	±30ppm	Series	40 Ohm
ECS-150-18-5PXEN	CSM-7X	MHz Crystal	15MHz	±50ppm	±30ppm	18pF	40 Ohm
ECS-150-S-5PX-TR	CSM-7X	MHz Crystal	15MHz	±50ppm	±30ppm	Series	40 Ohm
ECS-160.003-18-5PXEN-TR	CSM-7X	MHz Crystal	16.000312MHz	±50ppm	±30ppm	18pF	40 Ohm
ECS-160.003-18-5PX-TR	CSM-7X	MHz Crystal	16.000312MHz	±50ppm	±30ppm	18pF	40 Ohm
ECS-160-18-5PXEN-TR	CSM-7X	MHz Crystal	16MHz	±50ppm	±30ppm	18pF	40 Ohm
ECS-160-20-5PX-TR	CSM-7X	MHz Crystal	16MHz	±50ppm	±30ppm	20pF	40 Ohm
ECS-160-S-5PX-TR	CSM-7X	MHz Crystal	16MHz	±50ppm	±30ppm	Series	40 Ohm
ECS-162.57-18-5PXEN-TR	CSM-7X	MHz Crystal	16.257MHz	±50ppm	±30ppm	18pF	40 Ohm
ECS-163-18-5PXEN-TR	CSM-7X	MHz Crystal	16.384MHz	±50ppm	±30ppm	18pF	40 Ohm
ECS-177.3-18-5PXEN	CSM-7X	MHz Crystal	17.734475MHz	±50ppm	±30ppm	18pF	40 Ohm
ECS-180-18-5PXEN	CSM-7X	MHz Crystal	18MHz	±50ppm	±30ppm	18pF	40 Ohm
ECS-180-S-5PX-TR	CSM-7X	MHz Crystal	18MHz	±50ppm	±30ppm	Series	40 Ohm
ECS-184-18-5PX-TR	CSM-7X	MHz Crystal	18.432MHz	±50ppm	±30ppm	18pF	40 Ohm
ECS-184-20-5PX-TR	CSM-7X	MHz Crystal	18.432MHz	±50ppm	±30ppm	20pF	40 Ohm
ECS-184-S-5PX-TR	CSM-7X	MHz Crystal	18.432MHz	±50ppm	±30ppm	Series	40 Ohm
ECS-196.6-18-5PXEN-TR	CSM-7X	MHz Crystal	19.6608MHz	±50ppm	±30ppm	18pF	40 Ohm
ECS-196.6-20-5PX-TR	CSM-7X	MHz Crystal	19.6608MHz	±50ppm	±30ppm	20pF	40 Ohm
ECS-200-16-5PX-TR	CSM-7X	MHz Crystal	20MHz	±50ppm	±30ppm	16pF	30 Ohm
ECS-200-18-5PXEN-TR	CSM-7X	MHz Crystal	20MHz	±50ppm	±30ppm	18pF	30 Ohm
ECS-200-20-5PX-TR	CSM-7X	MHz Crystal	20MHz	±50ppm	±30ppm	20pF	30 Ohm
ECS-200-S-5PX-TR	CSM-7X	MHz Crystal	20MHz	±50ppm	±30ppm	Series	30 Ohm
ECS-204.8-20-5PX	CSM-7X	MHz Crystal	20.48MHz	±50ppm	±30ppm	20pF	30 Ohm
ECS-221-18-5PXEN-TR	CSM-7X	MHz Crystal	22.1184MHz	±50ppm	±30ppm	18pF	30 Ohm
ECS-240-12-5PX-TR	CSM-7X	MHz Crystal	24MHz	±50ppm	±30ppm	12pF	30 Ohm
ECS-240-16-5PX-TR	CSM-7X	MHz Crystal	24MHz	±50ppm	±30ppm	16pF	30 Ohm
ECS-240-18-5PXEN-TR	CSM-7X	MHz Crystal	24MHz	±50ppm	±30ppm	18pF	30 Ohm
ECS-240-20-5PX-TR	CSM-7X	MHz Crystal	24MHz	±50ppm	±30ppm	20pF	30 Ohm
ECS-245.7-18-5PXEN-TR	CSM-7X	MHz Crystal	24.576MHz	±50ppm	±30ppm	18pF	30 Ohm
ECS-245.7-20-5PX-TR	CSM-7X	MHz Crystal	24.576MHz	±50ppm	±30ppm	20pF	30 Ohm
ECS-250-18-5PX-F-TR	CSM-7X	MHz Crystal	25MHz	±50ppm	±30ppm	18pF	30 Ohm
ECS-251.75-18-5PX-EN-TR	CSM-7X	MHz Crystal	25.175MHz	±50ppm	±30ppm	18pF	30 Ohm
ECS-270-18-5PX-F-TR	CSM-7X	MHz Crystal	27MHz	±50ppm	±30ppm	18pF	30 Ohm
ECS-286.3-18-5PX-F-EN-TR	CSM-7X	MHz Crystal	28.63636MHz	±50ppm	±30ppm	18pF	30 Ohm
