XRCGB25M000F3M00R0,村田Murata,Murata晶振,村田晶振,Murata无源晶振,Murata谐振器

原厂型号 Original model ：	XRCGB25M000F3M00R0
品牌 brand ：	村田Murata
型号名称 Model name：	XRCGB
Type 系列：	MHz石英晶振
频率 frequency ：	25 MHz
Frequency Stability频率稳定度	±40ppm
frequency tolerance 频率容差	±30ppm
Load capacitance 负载电容	6pF
Size / Dimension 尺寸	2.00mm x 1.60mm

订购热线：0755-27838351

XRCGB25M000F3M00R0,村田Murata,Murata晶振,村田晶振,Murata无源晶振,Murata谐振器

原厂型号 Original model ：	XRCGB25M000F3M00R0	品牌 brand ：	Murata Electronics
品牌 brand ：	村田Murata	ESR (Equivalent Series Resistance)ESR（等效串联电阻）	50 kOhms
型号名称 Model name：	XRCGB	Operating Temperature温度	-40°C ~ 85°C
Type 系列：	MHz Crystal	Termination 脚位	4 pad
频率 frequency ：	25 MHz	Package Type 封装类型	4-SMD
Frequency Stability频率稳定度	±40ppm	Package Height 高度	0.70mm
frequency tolerance 频率容差	±30ppm	最小包装数 MPQ ：	3000 / reel
Load capacitance 负载电容	6pF	Packaging 包装	Tape and Reel
Size / Dimension 尺寸	2.00mm x 1.60mm	Mounting Style 安装方式	Surface Mount

XRCGB25M000F3M00R0,村田Murata,Murata晶振,村田晶振,Murata无源晶振,Murata谐振器

XRCGB25M000F3M00R0	村田Murata	XRCGB	MHz Crystal	25 MHz	±40ppm	±30ppm	6pF	150 Ohms
XRCGB27M120F3M00R0	村田Murata	XRCGB	MHz Crystal	27.12 MHz	±40ppm	±30ppm	6pF	150 Ohms
XRCGB24M000F3M00R0	村田Murata	XRCGB	MHz Crystal	24 MHz	±40ppm	±30ppm	6pF	150 Ohms
XRCGB24M000F2P00R0	村田Murata	XRCGB	MHz Crystal	24 MHz	±20ppm	±20ppm	6pF	150 Ohms
XRCGB32M000F1H01R0	村田Murata	-	MHz Crystal	32 MHz	±10ppm	±10ppm	8pF	60 Ohms
XRCGB32M000F1H00R0	村田Murata	XRCGB	MHz Crystal	32 MHz	±10ppm	±10ppm	6pF	60 Ohms
XRCGB25M000F3A00R0	村田Murata	XRCGB	MHz Crystal	25 MHz	±35ppm	±35ppm	6pF	100 Ohms
XRCGB24M000F0L00R0	村田Murata	XRCGB	MHz Crystal	24 MHz	±50ppm	±100ppm	6pF	150 Ohms
XRCGB48M000F4M00R0	村田Murata	XRCGB晶振	MHz Crystal	48 MHz	±40ppm	±45ppm	6pF	100 Ohms
XRCGB24M000F3N00R0	村田Murata	XRCGB晶振	MHz Crystal	24 MHz	±30ppm	±30ppm	6pF	150 Ohms
XRCGB27M120F3M10R0	村田Murata	XRCGB晶振	MHz Crystal	27.12 MHz	±40ppm	±30ppm	10pF	80 Ohms
XRCGB25M000F3M18R0	村田Murata	XRCGB晶振	MHz Crystal	25 MHz	±40ppm	±30ppm	12pF	80 Ohms
XRCGB32M000F2P01R0	村田Murata	XRCGB晶振	MHz Crystal	32 MHz	±20ppm	±20ppm	8pF	100 Ohms
XRCGB32M000F2P00R0	村田Murata	XRCGB晶振	MHz Crystal	32 MHz	±20ppm	±20ppm	6pF	100 Ohms
XRCGB25M000F2P02R0	村田Murata	XRCGB晶振	MHz Crystal	25 MHz	±20ppm	±20ppm	10pF	150 Ohms
XRCGB27M120F2P00R0	村田Murata	XRCGB晶振	MHz Crystal	27.12 MHz	±20ppm	±20ppm	6pF	150 Ohms
XRCGB25M000F2P00R0	村田Murata	XRCGB晶振	MHz Crystal	25 MHz	±20ppm	±20ppm	6pF	150 Ohms
XRCGB24M000F2P01R0	村田Murata	XRCGB晶振	MHz Crystal	24 MHz	±20ppm	±20ppm	8pF	150 Ohms
XRCGB27M120F3M13R0	村田Murata	XRCGB晶振	MHz Crystal	27.12 MHz	±40ppm	±30ppm	10pF	60 Ohms
XRCGB32M000F2P2CR0	村田Murata	XRCGB晶振	MHz Crystal	32 MHz	±20ppm	±20ppm	8pF	70 Ohms
XRCGB32M000FBH50R0	村田Murata	XRCGB晶振	MHz Crystal	32 MHz	±10ppm	±15ppm	10pF	60 Ohms
XRCGB24M000F2P91R0	村田Murata	XRCGB晶振	MHz Crystal	24 MHz	±20ppm	±20ppm	8pF	60 Ohms
XRCGB16M000FXN00R0	村田Murata	XRCGB晶振	MHz Crystal	16 MHz	±40ppm	±40ppm	6pF	200 Ohms
XRCGB32M000F1H02R0	村田Murata	XRCGB晶振	MHz Crystal	32 MHz	±10ppm	±10ppm	10pF	60 Ohms
XRCGB32M000F1H19R0	村田Murata	XRCGB晶振	MHz Crystal	32 MHz	±10ppm	±10ppm	6pF	50 Ohms
XRCGB40M000F5A00R0	村田Murata	XRCGB晶振	MHz Crystal	40 MHz	±65ppm	±50ppm	6pF	70 Ohms
XRCGB24M000F3A00R0	村田Murata	XRCGB晶振	MHz Crystal	24 MHz	±35ppm	±30ppm	6pF	120 Ohms
XRCGB27M120F3A00R0	村田Murata	XRCGB晶振	MHz Crystal	27.12 MHz	±35ppm	±30ppm	6pF	80 Ohms
XRCGB25M000F3A01R0	村田Murata	XRCGB晶振	MHz Crystal	25 MHz	±35ppm	±30ppm	8pF	100 Ohms
XRCGB48M000F5A00R0	村田Murata	XRCGB晶振	MHz Crystal	48 MHz	±65ppm	±50ppm	6pF	60 Ohms
XRCGE25M000FBA1AR0	村田Murata	XRCGB晶振	MHz Crystal	25 MHz	±35ppm	±15ppm	6pF	100 Ohms
XRCHA20M000F0A01R0	村田Murata	XRCGB晶振	MHz Crystal	20 MHz	±100ppm	±100ppm	8pF	80 Ohms
XRCGB27M120F0L00R0	村田Murata	XRCGB晶振	MHz Crystal	27.12 MHz	±50ppm	±100ppm	6pF	150 Ohms
XRCGB32M000F0L00R0	村田Murata	XRCGB晶振	MHz Crystal	32 MHz	±50ppm	±100ppm	6pF	100 Ohms
XRCGB24M000FAN00R0	村田Murata	XRCGB晶振	MHz Crystal	24 MHz	±40ppm	±25ppm	6pF	150 Ohms
XRCGB38M400F4M00R0	村田Murata	XRCGB晶振	MHz Crystal	38.4 MHz	±40ppm	±45ppm	6pF	100 Ohms
XRCGB50M000F4M00R0	村田Murata	XRCGB晶振	MHz Crystal	50 MHz	±40ppm	±45ppm	6pF	65 Ohms
XRCGB32M000F3M00R0	村田Murata	XRCGB晶振	MHz Crystal	32 MHz	±40ppm	±30ppm	6pF	100 Ohms
XRCGB24M000F3M13R0	村田Murata	XRCGB晶振	MHz Crystal	24 MHz	±40ppm	±30ppm	6pF	150 Ohms
XRCGB32M000F2P02R0	村田Murata	XRCGB晶振	MHz Crystal	32 MHz	±20ppm	±20ppm	10pF	100 Ohms
XRCGB30M000F2P00R0	村田Murata	XRCGB晶振	MHz Crystal	30 MHz	±20ppm	±20ppm	6pF	100 Ohms
XRCGB27M120F2P02R0	村田Murata	XRCGB晶振	MHz Crystal	27.12 MHz	±20ppm	±20ppm	10pF	150 Ohms
XRCGB32M000F2P26R0	村田Murata	XRCGB晶振	MHz Crystal	32 MHz	±20ppm	±20ppm	5pF	70 Ohms
XRCGB31M250F2P00R0	村田Murata	XRCGB晶振	MHz Crystal	31.25 MHz	±20ppm	±20ppm	6pF	100 Ohms
XRCGB27M120F3G00R0	村田Murata	XRCGB晶振	MHz Crystal	27.12 MHz	±50ppm	±30ppm	6pF	150 Ohms
XRCGB16M000FXN22R0	村田Murata	XRCGB晶振	MHz Crystal	16 MHz	±40ppm	±40ppm	8pF	200 Ohms
XRCGB27M600F2C00R0	村田Murata	XRCGB晶振	MHz Crystal	27.6 MHz	±20ppm	±20ppm	6pF	80 Ohms
XRCGB24M000F1H01R0	村田Murata	XRCGB晶振	MHz Crystal	24 MHz	±10ppm	±10ppm	8pF	80 Ohms
XRCGB26M000F1H02R0	村田Murata	XRCGB晶振	MHz Crystal	26 MHz	±10ppm	±10ppm	10pF	60 Ohms
XRCGB24M000F1H70R0	村田Murata	XRCGB晶振	MHz Crystal	24 MHz	±20ppm	±10ppm	6pF	80 Ohms
XRCGB32M000F1H83R0	村田Murata	XRCGB晶振	MHz Crystal	32 MHz	±15ppm	±10ppm	9pF	60 Ohms
XRCGE27M000FBA1AR0	村田Murata	XRCGB晶振	MHz Crystal	27 MHz	±35ppm	±15ppm	6pF	80 Ohms
XRCGB26M000F3A00R0	村田Murata	XRCGB晶振	MHz Crystal	26 MHz	±35ppm	±30ppm	6pF	80 Ohms
XRCGE26M000FBA1BR0	村田Murata	XRCGB晶振	MHz Crystal	26 MHz	±35ppm	±15ppm	8pF	80 Ohms
XRCGE20M000F3A1AR0	村田Murata	XRCGB晶振	MHz Crystal	20 MHz	±45ppm	±30ppm	6pF	150 Ohms
XRCGB24M000F2A01R0	村田Murata	XRCGB晶振	MHz Crystal	24 MHz	±35ppm	±20ppm	8pF	120 Ohms
XRCGB27M120F3P00R0	村田Murata	XRCGB晶振	MHz Crystal	27.12 MHz	±20ppm	±30ppm	6pF	150 Ohms
XRCGB32M000F2P55R0	村田Murata	XRCGB晶振	MHz Crystal	32 MHz	±20ppm	±20ppm	6pF	80 Ohms
XRCPB26M000F2P00R0	村田Murata	XRCGB晶振	MHz Crystal	26 MHz	±20ppm	±20ppm	6pF	150 Ohms
XRCGB32M000F1H18R0	村田Murata	XRCGB晶振	MHz Crystal	32 MHz	±15ppm	±10ppm	9pF	40 Ohms
