NX5032GA-24.000000MHZ-LN-CD-1,NDK无源晶振,NDK无源谐振器,NDK陶瓷晶振,NX5032GA
| 原厂型号 Original model ： | NX5032GA-24.000000MHZ-LN-CD-1 |
| 品牌 brand ： | NDK晶振 |
| 型号名称 Model name： | NX5032GA |
| Type 系列： | MHz晶振 |
| 频率 frequency ： | 24MHz |
| Frequency Stability频率稳定度 | ±50ppm无源晶振 |
| frequency tolerance频率容差 | ±50ppm |
| Load capacitance 负载电容 | 8pF |
| Size / Dimension 尺寸 | 5.00mm x 3.20mm |
订购热线：0755-27838351
NX5032GA-24.000000MHZ-LN-CD-1,NDK无源晶振,NDK无源谐振器,NDK陶瓷晶振,NX5032GA
| 原厂型号 Original model ： | NX5032GA-24.000000MHZ-LN-CD-1 | 品牌 brand ： | NDK晶振 |
| 品牌 brand ： | NDK晶振 | ESR (Equivalent Series Resistance)ESR（等效串联电阻） | 70 Ohm |
| 型号名称 Model name： | NX5032GA | Operating Temperature温度 | -10°C ~ 70°C |
| Type 系列： | MHz晶振 | Termination 脚位 | 2 pad |
| 频率 frequency ： | 24MHz | Package Type 封装类型 | 2-SMD |
| Frequency Stability频率稳定度 | ±50ppm | Package Height 高度 | 1.50mm |
| frequency tolerance 频率容差 | ±50ppm | 最小包装数 MPQ ： | 3000 / reel |
| Load capacitance 负载电容 | 8pF | Packaging 包装 | Tape and Reel |
| Size / Dimension 尺寸 | 5.00mm x 3.20mm | Mounting Style 安装方式 | Surface Mount |
NX5032GA-24.000000MHZ-LN-CD-1,NDK无源晶振,NDK无源谐振器,NDK陶瓷晶振,NX5032GA
| NX8045GB-40.000000MHZ | NDK晶振 | NX8045GB | 40MHz | ±50ppm | ±50ppm | 8pF | 50 Ohm |
| NX8045GB-40.000000MHZ | NDK晶振 | NX8045GB | 40MHz | ±50ppm | ±50ppm | 8pF | 50 Ohm |
| NX8045GB-40.000000MHZ | NDK晶振 | NX8045GB | 40MHz | ±50ppm | ±50ppm | 8pF | 50 Ohm |
| NX5032GA-24.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 24MHz | ±50ppm | ±50ppm | 8pF | 70 Ohm |
| NX5032GA-24.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 24MHz | ±50ppm | ±50ppm | 8pF | 70 Ohm |
| NX5032GA-24.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 24MHz | ±50ppm | ±50ppm | 8pF | 70 Ohm |
| NX5032GA-25.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 25MHz | ±50ppm | ±50ppm | 8pF | 70 Ohm |
| NX5032GA-25.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 25MHz | ±50ppm | ±50ppm | 8pF | 70 Ohm |
| NX5032GA-25.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 25MHz | ±50ppm | ±50ppm | 8pF | 70 Ohm |
| NX5032GA-27.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 27MHz | ±50ppm | ±50ppm | 8pF | 70 Ohm |
| NX5032GA-27.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 27MHz | ±50ppm | ±50ppm | 8pF | 70 Ohm |
| NX5032GA-27.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 27MHz | ±50ppm | ±50ppm | 8pF | 70 Ohm |
| NX5032GA-16.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 16MHz | ±50ppm | ±50ppm | 8pF | 120 Ohm |
| NX5032GA-16.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 16MHz | ±50ppm | ±50ppm | 8pF | 120 Ohm |
| NX5032GA-16.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 16MHz | ±50ppm | ±50ppm | 8pF | 120 Ohm |
| NX5032GA-10.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 10MHz | ±50ppm | ±50ppm | 8pF | 120 Ohm |
| NX5032GA-10.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 10MHz | ±50ppm | ±50ppm | 8pF | 120 Ohm |
| NX5032GA-10.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 10MHz | ±50ppm | ±50ppm | 8pF | 120 Ohm |
| NX5032GA-12.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 12MHz | ±50ppm | ±50ppm | 8pF | 120 Ohm |
| NX5032GA-12.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 12MHz | ±50ppm | ±50ppm | 8pF | 120 Ohm |
| NX5032GA-12.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 12MHz | ±50ppm | ±50ppm | 8pF | 120 Ohm |
| NX5032GA-48.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 48MHz | ±50ppm | ±50ppm | 8pF | 50 Ohm |
| NX5032GA-48.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 48MHz | ±50ppm | ±50ppm | 8pF | 50 Ohm |
| NX5032GA-48.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 48MHz | ±50ppm | ±50ppm | 8pF | 50 Ohm |
| NX5032GA-16.384000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 16.384MHz | ±50ppm | ±50ppm | 8pF | 120 Ohm |
| NX5032GA-16.384000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 16.384MHz | ±50ppm | ±50ppm | 8pF | 120 Ohm |
| NX5032GA-16.384000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 16.384MHz | ±50ppm | ±50ppm | 8pF | 120 Ohm |
| NX5032GA-20.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 20MHz | ±50ppm | ±50ppm | 8pF | 70 Ohm |
| NX5032GA-20.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 20MHz | ±50ppm | ±50ppm | 8pF | 70 Ohm |
| NX5032GA-20.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 20MHz | ±50ppm | ±50ppm | 8pF | 70 Ohm |
| NX5032GA-32.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 32MHz | ±50ppm | ±50ppm | 8pF | 50 Ohm |
| NX5032GA-32.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 32MHz | ±50ppm | ±50ppm | 8pF | 50 Ohm |
| NX5032GA-32.000000MHZ-LN-CD-1 | NDK晶振 | NX5032GA | 32MHz | ±50ppm | ±50ppm | 8pF | 50 Ohm |
| NX3225GA-26MHZ-TI | NDK晶振 | NX3225GA | 26MHz | ±40ppm | ±20ppm | 10pF | 50 Ohm |
| NX3225GA-26MHZ-TI | NDK晶振 | NX3225GA | 26MHz | ±40ppm | ±20ppm | 10pF | 50 Ohm |
| NX3225GA-26MHZ-TI | NDK晶振 | NX3225GA | 26MHz | ±40ppm | ±20ppm | 10pF | 50 Ohm |
| NX3225GA-16.000M-STD-CRG-2 | NDK晶振 | NX3225GA | 16MHz | ±30ppm | ±20ppm | 8pF | 80 Ohm |
| NX3225GA-16.000M-STD-CRG-2 | NDK晶振 | NX3225GA | 16MHz | ±30ppm | ±20ppm | 8pF | 80 Ohm |
| NX3225GA-16.000M-STD-CRG-2 | NDK晶振 | NX3225GA | 16MHz | ±30ppm | ±20ppm | 8pF | 80 Ohm |
| NX3225GA-27.000M-STD-CRG-1 | NDK晶振 | NX3225GA | 27MHz | ±30ppm | ±20ppm | 8pF | 50 Ohm |
| NX3225GA-27.000M-STD-CRG-1 | NDK晶振 | NX3225GA | 27MHz | ±30ppm | ±20ppm | 8pF | 50 Ohm |
| NX3225GA-27.000M-STD-CRG-1 | NDK晶振 | NX3225GA | 27MHz | ±30ppm | ±20ppm | 8pF | 50 Ohm |
| NX3225SA-24.000MHZ-STD-CSR-1 | NDK晶振 | NX3225SA | 24MHz | ±15ppm | ±15ppm | 8pF | 50 Ohm |
| NX3225SA-24.000MHZ-STD-CSR-1 | NDK晶振 | NX3225SA | 24MHz | ±15ppm | ±15ppm | 8pF | 50 Ohm |
| NX3225SA-24.000MHZ-STD-CSR-1 | NDK晶振 | NX3225SA | 24MHz | ±15ppm | ±15ppm | 8pF | 50 Ohm |
| NX5032GA-27M-STD-CSK-4 | NDK晶振 | NX5032GA | 27MHz | ±30ppm | ±20ppm | 8pF | 50 Ohm |
| NX5032GA-27M-STD-CSK-4 | NDK晶振 | NX5032GA | 27MHz | ±30ppm | ±20ppm | 8pF | 50 Ohm |
| NX5032GA-27M-STD-CSK-4 | NDK晶振 | NX5032GA | 27MHz | ±30ppm | ±20ppm | 8pF | 50 Ohm |
| NX5032GA-12.288M-STD-CSK-4 | NDK晶振 | NX5032GA | 12.288MHz | ±30ppm | ±20ppm | 8pF | 100 Ohm |
| NX5032GA-12.288M-STD-CSK-4 | NDK晶振 | NX5032GA | 12.288MHz | ±30ppm | ±20ppm | 8pF | 100 Ohm |
| NX5032GA-12.288M-STD-CSK-4 | NDK晶振 | NX5032GA | 12.288MHz | ±30ppm | ±20ppm | 8pF | 100 Ohm |
| NX5032GA-14.31818M-STD-CSK-4 | NDK晶振 | NX5032GA | 14.31818MHz | ±30ppm | ±20ppm | 8pF | 100 Ohm |
| NX5032GA-14.31818M-STD-CSK-4 | NDK晶振 | NX5032GA | 14.31818MHz | ±30ppm | ±20ppm | 8pF | 100 Ohm |
| NX5032GA-14.31818M-STD-CSK-4 | NDK晶振 | NX5032GA | 14.31818MHz | ±30ppm | ±20ppm | 8pF | 100 Ohm |
| NX5032GA-25.000M-STD-CSK-4 | NDK晶振 | NX5032GA | 25MHz | ±30ppm | ±20ppm | 8pF | 50 Ohm |
| NX5032GA-25.000M-STD-CSK-4 | NDK晶振 | NX5032GA | 25MHz | ±30ppm | ±20ppm | 8pF | 50 Ohm |
| NX5032GA-25.000M-STD-CSK-4 | NDK晶振 | NX5032GA | 25MHz | ±30ppm | ±20ppm | 8pF | 50 Ohm |
| NX5032GC-16MHZ-STD-CSK-6 | NDK晶振 | NX5032GC | 16MHz | ±15ppm | ±15ppm | 8pF | 50 Ohm |
| NX5032GC-16MHZ-STD-CSK-6 | NDK晶振 | NX5032GC | 16MHz | ±15ppm | ±15ppm | 8pF | 50 Ohm |
| NX5032GC-16MHZ-STD-CSK-6 | NDK晶振 | NX5032GC | 16MHz | ±15ppm | ±15ppm | 8pF | 50 Ohm |
