NX3225SC-30.320M-EXS00A-CS03981,NDK进口晶振,日产晶振,NDK四脚贴片晶振,2520mm晶振

原厂型号 Original model ：	NX3225SC-30.320M-EXS00A-CS03981
品牌 brand ：	NDK晶振
型号名称 Model name：	NX3225SC
Type 系列：	MHz晶振
频率 frequency ：	30.32MHz
Frequency Stability频率稳定度	±25ppm
frequency tolerance频率容差	±10ppm
Load capacitance 负载电容	6pF
Size / Dimension 尺寸	3.20mm x 2.50mm

订购热线：0755-27838351

NX3225SC-30.320M-EXS00A-CS03981,NDK进口晶振,日产晶振,NDK四脚贴片晶振,2520mm晶振,车规温度,耐高温晶振

原厂型号 Original model ：	NX3225SC-30.320M-EXS00A-CS03981	品牌 brand ：	NDK晶振
品牌 brand ：	NDK晶振	ESR (Equivalent Series Resistance)ESR（等效串联电阻）	100 Ohm
型号名称 Model name：	NX3225SC	Operating Temperature温度	-40°C ~ 125°C
Type 系列：	MHz晶振	Termination 脚位	4 pad
频率 frequency ：	30.32MHz	Package Type 封装类型	4-SMD
Frequency Stability频率稳定度	±25ppm	Package Height 高度	0.70mm
frequency tolerance 频率容差	±10ppm	最小包装数 MPQ ：	3000 / reel
Load capacitance 负载电容	6pF	Packaging 包装	Tape and Reel
Size / Dimension 尺寸	3.20mm x 2.50mm	Mounting Style 安装方式	Surface Mount

NX3225SC-30.320M-EXS00A-CS03981,NDK进口晶振,日产晶振,NDK四脚贴片晶振,2520mm晶振,车规温度,耐高温晶振

NX3225SA-25.000M-STD-CRS-2	NDK晶振	NX3225SA	25MHz	±50ppm	±15ppm	8pF	100 Ohm
NX3225SA-27M-STD-CRS-2	NDK晶振	NX3225SA	27MHz	±50ppm	±15ppm	8pF	100 Ohm
NX3225SA-27M-STD-CRS-2	NDK晶振	NX3225SA	27MHz	±50ppm	±15ppm	8pF	100 Ohm
NX3225SA-27M-STD-CRS-2	NDK晶振	NX3225SA	27MHz	±50ppm	±15ppm	8pF	100 Ohm
NX3225SC-30.320M-EXS00A-CS03981	NDK晶振	NX3225SC	30.32MHz	±25ppm	±10ppm	6pF	100 Ohm
NX3225SC-30.320M-EXS00A-CS03981	NDK晶振	NX3225SC	30.32MHz	±25ppm	±10ppm	6pF	100 Ohm
NX3225SC-30.320M-EXS00A-CS03981	NDK晶振	NX3225SC	30.32MHz	±25ppm	±10ppm	6pF	100 Ohm
NX3225SA-12MHZ-STD-CSR-6	NDK晶振	NX3225SA	12MHz	±25ppm	±15ppm	8pF	100 Ohm
NX3225SA-12MHZ-STD-CSR-6	NDK晶振	NX3225SA	12MHz	±25ppm	±15ppm	8pF	100 Ohm
NX3225SA-12MHZ-STD-CSR-6	NDK晶振	NX3225SA	12MHz	±25ppm	±15ppm	8pF	100 Ohm
NX3225SA-16MHZ-STD-CSR-6	NDK晶振	NX3225SA	16MHz	±25ppm	±15ppm	8pF	80 Ohm
NX3225SA-16MHZ-STD-CSR-6	NDK晶振	NX3225SA	16MHz	±25ppm	±15ppm	8pF	80 Ohm
NX3225SA-16MHZ-STD-CSR-6	NDK晶振	NX3225SA	16MHz	±25ppm	±15ppm	8pF	80 Ohm
NX3225SA-26.000000MHZ-G4	NDK晶振	NX3225SA	26MHz	±10ppm	±10ppm	10pF	50 Ohm
NX3225SA-26.000000MHZ-G4	NDK晶振	NX3225SA	26MHz	±10ppm	±10ppm	10pF	50 Ohm
NX3225SA-26.000000MHZ-G4	NDK晶振	NX3225SA	26MHz	±10ppm	±10ppm	10pF	50 Ohm
NX3225SA-26.000000MHZ-B1	NDK晶振	NX3225SA	26MHz	±10ppm	±10ppm	10pF	50 Ohm
NX3225SA-26.000000MHZ-B1	NDK晶振	NX3225SA	26MHz	±10ppm	±10ppm	10pF	50 Ohm
NX3225SA-26.000000MHZ-B1	NDK晶振	NX3225SA	26MHz	±10ppm	±10ppm	10pF	50 Ohm
NX3225SA-16.000000MHZ-T1	NDK晶振	NX3225SA	16MHz	±10ppm	±10ppm	10pF	60 Ohm
NX3225SA-16.000000MHZ-T1	NDK晶振	NX3225SA	16MHz	±10ppm	±10ppm	10pF	60 Ohm
NX3225SA-16.000000MHZ-T1	NDK晶振	NX3225SA	16MHz	±10ppm	±10ppm	10pF	60 Ohm
NX3225SA-26.000000MHZ-G2	NDK晶振	NX3225SA	26MHz	±11ppm	±10ppm	10pF	50 Ohm
NX3225SA-26.000000MHZ-G2	NDK晶振	NX3225SA	26MHz	±11ppm	±10ppm	10pF	50 Ohm
NX3225SA-26.000000MHZ-G2	NDK晶振	NX3225SA	26MHz	±11ppm	±10ppm	10pF	50 Ohm
NX3225SA-16.000000MHZ-B3	NDK晶振	NX3225SA	16MHz	±15ppm	±10ppm	7.2pF	80 Ohm
NX3225SA-16.000000MHZ-B3	NDK晶振	NX3225SA	16MHz	±15ppm	±10ppm	7.2pF	80 Ohm
NX3225SA-16.000000MHZ-B3	NDK晶振	NX3225SA	16MHz	±15ppm	±10ppm	7.2pF	80 Ohm
NX3225SA-26.000000MHZ-G3	NDK晶振	NX3225SA	26MHz	±10ppm	±10ppm	7.36pF	50 Ohm
NX3225SA-26.000000MHZ-G3	NDK晶振	NX3225SA	26MHz	±10ppm	±10ppm	7.36pF	50 Ohm
NX3225SA-26.000000MHZ-G3	NDK晶振	NX3225SA	26MHz	±10ppm	±10ppm	7.36pF	50 Ohm
NX3225SA-39.000000MHZ-B4	NDK晶振	NX3225SA	39MHz	±10ppm	±10ppm	12pF	50 Ohm
NX3225SA-39.000000MHZ-B4	NDK晶振	NX3225SA	39MHz	±10ppm	±10ppm	12pF	50 Ohm
NX3225SA-39.000000MHZ-B4	NDK晶振	NX3225SA	39MHz	±10ppm	±10ppm	12pF	50 Ohm
NX3215SA-32.768K-STD-MUA-8	NDK晶振	NX3215SA	32.768kHz	-	±20ppm	12.5pF	70 kOhm
NX3215SA-32.768K-STD-MUA-8	NDK晶振	NX3215SA	32.768kHz	-	±20ppm	12.5pF	70 kOhm
NX3215SA-32.768K-STD-MUA-8	NDK晶振	NX3215SA	32.768kHz	-	±20ppm	12.5pF	70 kOhm
NX3215SA-32.768K-STD-MUA-9	NDK晶振	NX3215SA	32.768kHz	-	±20ppm	9pF	70 kOhm
NX3215SA-32.768K-STD-MUA-9	NDK晶振	NX3215SA	32.768kHz	-	±20ppm	9pF	70 kOhm
NX3215SA-32.768K-STD-MUA-9	NDK晶振	NX3215SA	32.768kHz	-	±20ppm	9pF	70 kOhm
NX3215SA-32.768K-STD-MUA-14	NDK晶振	NX3215SA	32.768kHz	-	±20ppm	6pF	70 kOhm
NX3215SA-32.768K-STD-MUA-14	NDK晶振	NX3215SA	32.768kHz	-	±20ppm	6pF	70 kOhm
NX3215SA-32.768K-STD-MUA-14	NDK晶振	NX3215SA	32.768kHz	-	±20ppm	6pF	70 kOhm
NX3215SA-32.768K-STD-MUS-2	NDK晶振	NX3215SA	32.768kHz	-	±20ppm	12.5pF	70 kOhm
NX3215SA-32.768K-STD-MUS-2	NDK晶振	NX3215SA	32.768kHz	-	±20ppm	12.5pF	70 kOhm
NX3215SA-32.768K-STD-MUS-2	NDK晶振	NX3215SA	32.768kHz	-	±20ppm	12.5pF	70 kOhm
NX3225SA-20.000M-STD-CRS-2	NDK晶振	NX3225SA	20MHz	±50ppm	±15ppm	8pF	100 Ohm
NX3225SA-20.000M-STD-CRS-2	NDK晶振	NX3225SA	20MHz	±50ppm	±15ppm	8pF	100 Ohm
NX3225SA-20.000M-STD-CRS-2	NDK晶振	NX3225SA	20MHz	±50ppm	±15ppm	8pF	100 Ohm
NX3225SA-16.000M-STD-CRS-2	NDK晶振	NX3225SA	16MHz	±50ppm	±15ppm	8pF	120 Ohm
NX3225SA-16.000M-STD-CRS-2	NDK晶振	NX3225SA	16MHz	±50ppm	±15ppm	8pF	120 Ohm
NX3225SA-16.000M-STD-CRS-2	NDK晶振	NX3225SA	16MHz	±50ppm	±15ppm	8pF	120 Ohm
NX2520SG-19.2M-STD-CTX-1	NDK晶振	NX2520SG	19.2MHz	±12ppm	±10ppm	7pF	70 Ohm
NX2520SG-19.2M-STD-CTX-1	NDK晶振	NX2520SG	19.2MHz	±12ppm	±10ppm	7pF	70 Ohm
NX2520SG-19.2M-STD-CTX-1	NDK晶振	NX2520SG	19.2MHz	±12ppm	±10ppm	7pF	70 Ohm
NX2520SA-16MHZ-STD-CSW-4	NDK晶振	NX2520SA	16MHz	±15ppm	±15ppm	8pF	80 Ohm
NX2520SA-16MHZ-STD-CSW-4	NDK晶振	NX2520SA	16MHz	±15ppm	±15ppm	8pF	80 Ohm
NX2520SA-16MHZ-STD-CSW-4	NDK晶振	NX2520SA	16MHz	±15ppm	±15ppm	8pF	80 Ohm
NX8045GB-10.000000MHZ	NDK晶振	NX8045GB	10MHz	±50ppm	±50ppm	8pF	100 Ohm
NX8045GB-10.000000MHZ	NDK晶振	NX8045GB	10MHz	±50ppm	±50ppm	8pF	100 Ohm
