ECS-.320-12.5-13,ECS伊西斯圆柱晶振,ECS-31无源插件晶振
| 原厂型号 Original model ： | ECS-.320-12.5-13 |
| 品牌 brand ： | ECS晶振 |
| 型号名称 Model name： | ECS-31 |
| Type 系列： | kHz Crystal (Tuning Fork) |
| 频率 frequency ： | 32kHz |
| Frequency Stability频率稳定度 | - |
| frequency tolerance频率容差 | ±30ppm |
| Load capacitance 负载电容 | 12.5pF圆柱晶振 |
| Size / Dimension 尺寸 | 2.10mm x 6.20mm |
订购热线：0755-27838351
ECS-.320-12.5-13,ECS伊西斯圆柱晶振,ECS-31无源插件晶振
| 原厂型号 Original model ： | ECS-.320-12.5-13 | 品牌 brand ： | ECS伊西斯无源晶振 |
| 品牌 brand ： | ECS晶振 | ESR（等效串联电阻）ESR (Equivalent Series Resistance) | - |
| 型号名称 Model name： | ECS-31 | 温度 Operating Temperature | -10°C ~ 60°C |
| Type 系列： | kHz Crystal (Tuning Fork) | 脚位 Termination： | 2 pad |
| 频率 frequency ： | 32kHz | 封装类型 Package Type： | Cylindrical Can, Radial |
| Frequency Stability频率稳定度 | - | 高度 Package Height： | 6.20mm |
| frequency tolerance频率容差 | ±30ppm | 最小包装数 MPQ ： | - |
| Load capacitance 负载电容 | 12.5pF | 包装 Packaging： | Tape and Reel |
| Size / Dimension 尺寸 | 2.10mm x 6.20mm | 安装方式 Mounting Style： | Surface Mount |
ECS-.320-12.5-13,ECS伊西斯圆柱晶振,ECS-31无源插件晶振
| ECS-.320-12.5-13 | ECS-31 | kHz Crystal (Tuning Fork) | 32kHz | - | ±30ppm晶振 | 12.5pF |
| ECS-.400-12.5-13 | ECS-31 | kHz Crystal (Tuning Fork) | 40kHz | - | ±30ppm | 12.5pF |
| ECS-.600-12.5-13 | ECS-31 | kHz Crystal (Tuning Fork) | 60kHz | - | ±30ppm | 12.5pF |
| ECS-.655-12.5-13 | ECS-31 | kHz Crystal (Tuning Fork) | 65.536kHz | - | ±30ppm | 12.5pF |
| ECS-.750-12.5-13 | ECS-31 | kHz Crystal (Tuning Fork) | 75kHz | - | ±30ppm | 12.5pF |
| ECS-1.00-12.5-13 | ECS-31 | kHz Crystal (Tuning Fork) | 100kHz | - | ±30ppm | 12.5pF |
| ECS-1.25-12.5-13 | ECS-31 | kHz Crystal (Tuning Fork) | 125kHz | - | ±30ppm | 12.5pF |
| ECS-1.536-12.5-13 | ECS-31 | kHz Crystal (Tuning Fork) | 153.6kHz | - | ±30ppm | 12.5pF |
| ECS-.320-12.5-13X | ECS-31X | kHz Crystal (Tuning Fork) | 32kHz | - | ±30ppm | 12.5pF |
| ECS-.655-12.5-13X | ECS-31X | kHz Crystal (Tuning Fork) | 65.536kHz | - | ±30ppm | 12.5pF |
| ECS-1.00-12.5-13X | ECS-31X | kHz Crystal (Tuning Fork) | 100kHz | - | ±30ppm | 12.5pF |
| ECS-1.536-12.5-13X | ECS-31X | kHz Crystal (Tuning Fork) | 153.6kHz | - | ±30ppm | 12.5pF |
| ECS-35-18-10 | ECS-3x10 | MHz Crystal | 3.579545MHz | ±50ppm | ±50ppm | 18pF |
| ECS-36-18-10 | ECS-3x10 | MHz Crystal | 3.6864MHz | ±50ppm | ±50ppm | 18pF |
| ECS-400-18-10-3OT | ECS-3x10 | MHz Crystal | 40MHz | ±50ppm | ±50ppm | 18pF |
| ECS-40-18-10 | ECS-3x10 | MHz Crystal | 4MHz | ±50ppm | ±50ppm | 18pF |
| ECS-49-18-10 | ECS-3x10 | MHz Crystal | 4.9152MHz | ±50ppm | ±50ppm | 18pF |
| ECS-60-18-10 | ECS-3x10 | MHz Crystal | 6MHz | ±50ppm | ±50ppm | 18pF |
| ECS-73-18-10 | ECS-3x10 | MHz Crystal | 7.3728MHz | ±50ppm | ±50ppm | 18pF |
| ECS-80-18-10 | ECS-3x10 | MHz Crystal | 8MHz | ±50ppm | ±50ppm | 18pF |
| ECS-35-18-10X | ECS-3X10X | MHz Crystal | 3.579545MHz | ±50ppm | ±50ppm | 18pF |
| ECS-36-18-10X | ECS-3X10X | MHz Crystal | 3.6864MHz | ±50ppm | ±50ppm | 18pF |
| ECS-40-18-10X | ECS-3X10X | MHz Crystal | 4MHz | ±50ppm | ±50ppm | 18pF |
| ECS-49-18-10X | ECS-3X10X | MHz Crystal | 4.9152MHz | ±50ppm | ±50ppm | 18pF |
| ECS-60-18-10X | ECS-3X10X | MHz Crystal | 6MHz | ±50ppm | ±50ppm | 18pF |
| ECS-73-18-10X | ECS-3X10X | MHz Crystal | 7.3728MHz | ±50ppm | ±50ppm | 18pF |
| ECS-80-18-10X | ECS-3X10X | MHz Crystal | 8MHz | ±50ppm | ±50ppm | 18pF |
| ECS-3X8 | ECS-3X8 | kHz Crystal (Tuning Fork) | 32.768kHz | - | ±20ppm | 12.5pF |
| ECS-3X8X | ECS-3X8X | kHz Crystal (Tuning Fork) | 32.768kHz | - | ±20ppm | 12.5pF |
| ECS-100-18-9 | ECS-3x9 | MHz Crystal | 10MHz | ±50ppm | ±50ppm | 18pF |
| ECS-110.5-18-9 | ECS-3x9 | MHz Crystal | 11.0592MHz | ±50ppm | ±50ppm | 18pF |
| ECS-120-18-9 | ECS-3x9 | MHz Crystal | 12MHz | ±50ppm | ±50ppm | 18pF |
| ECS-143-18-9 | ECS-3x9 | MHz Crystal | 14.31818MHz | ±50ppm | ±50ppm | 18pF |
| ECS-147.4-18-9 | ECS-3x9 | MHz Crystal | 14.7456MHz | ±50ppm | ±50ppm | 18pF |
| ECS-160-18-9 | ECS-3x9 | MHz Crystal | 16MHz | ±50ppm | ±50ppm | 18pF |
| ECS-184-18-9 | ECS-3x9 | MHz Crystal | 18.432MHz | ±50ppm | ±50ppm | 18pF |
| ECS-196.6-18-9 | ECS-3x9 | MHz Crystal | 19.6608MHz | ±50ppm | ±50ppm | 18pF |
| ECS-200-18-9 | ECS-3x9 | MHz Crystal | 20MHz | ±50ppm | ±50ppm | 18pF |
| ECS-240-18-9 | ECS-3x9 | MHz Crystal | 24MHz | ±50ppm | ±50ppm | 18pF |
| ECS-245.7-18-9 | ECS-3x9 | MHz Crystal | 24.576MHz | ±50ppm | ±50ppm | 18pF |
| ECS-250-18-9 | ECS-3x9 | MHz Crystal | 25MHz | ±50ppm | ±50ppm | 18pF |
| ECS-270-18-9 | ECS-3x9 | MHz Crystal | 27MHz | ±50ppm | ±50ppm | 18pF |
| ECS-320-18-9-F | ECS-3x9 | MHz Crystal | 32MHz | ±50ppm | ±50ppm | 18pF |
| ECS-327-18-9-F | ECS-3x9 | MHz Crystal | 32.768MHz | ±50ppm | ±50ppm | 18pF |
| ECS-500-18-9-3OT | ECS-3x9 | MHz Crystal | 50MHz | ±50ppm | ±50ppm | 18pF |
| ECS-81.92-18-9 | ECS-3x9 | MHz Crystal | 8.192MHz | ±50ppm | ±50ppm | 18pF |
| ECS-98.3-18-9 | ECS-3x9 | MHz Crystal | 9.8304MHz | ±50ppm | ±50ppm | 18pF |
| ECS-100-18-9X | ECS-3X9X | MHz Crystal | 10MHz | ±50ppm | ±50ppm | 18pF |
| ECS-110.5-18-9X | ECS-3X9X | MHz Crystal | 11.0592MHz | ±50ppm | ±50ppm | 18pF |
| ECS-120-18-9X | ECS-3X9X | MHz Crystal | 12MHz | ±50ppm | ±50ppm | 18pF |
| ECS-143-18-9X | ECS-3X9X | MHz Crystal | 14.31818MHz | ±50ppm | ±50ppm | 18pF |
| ECS-147.4-18-9X | ECS-3X9X | MHz Crystal | 14.7456MHz | ±50ppm | ±50ppm | 18pF |
| ECS-160-18-9X | ECS-3X9X | MHz Crystal | 16MHz | ±50ppm | ±50ppm | 18pF |
| ECS-184-18-9X | ECS-3X9X | MHz Crystal | 18.432MHz | ±50ppm | ±50ppm | 18pF |
| ECS-196.6-18-9X | ECS-3X9X | MHz Crystal | 19.6608MHz | ±50ppm | ±50ppm | 18pF |
| ECS-200-18-9X | ECS-3X9X | MHz Crystal | 20MHz | ±50ppm | ±50ppm | 18pF |
| ECS-245.7-18-9X | ECS-3X9X | MHz Crystal | 24.576MHz | ±50ppm | ±50ppm | 18pF |
| ECS-250-18-9X | ECS-3X9X | MHz Crystal | 25MHz | ±50ppm | ±50ppm | 18pF |
| ECS-270-18-9X | ECS-3X9X | MHz Crystal | 27MHz | ±50ppm | ±50ppm | 18pF |
| ECS-320-18-9X-F | ECS-3X9X | MHz Crystal | 32MHz | ±50ppm | ±50ppm | 18pF |
ECS-.320-12.5-13,ECS伊西斯圆柱晶振,ECS-31无源插件晶振
